TH-190.04 (16kW) HSK-A63/HSK-C63 15,000rpm
Product Information
| Type | TH-190.04 (400V) |
||
|---|---|---|---|
| Spindle Ø | 190mm | ||
| Maximum Speed (Oil-Air) | 15,000rpm | ||
| Bore diameter of front bearings | 70mm | ||
| Rigidity | Axial (N/µm) |
180N/µm | |
| Radial (N/µm) |
200N/µm | ||
| Frequency Max. (Hz) | 800Hz | ||
| at speed | 3,200RPM | ||
| S1 kW | 16kW | ||
| S1 Current (A) | 69A | ||
| S6-40% kW | 20.8kW | ||
| S6-40% Current (A) | 90A | ||
| kW (Peak Power) | 63kW | ||
| S1 Torque (Nm) | 47.8Nm | ||
| S6-40% Torque (Nm) | 62.1Nm | ||
| Tool Interface | HSK-C63 | HSK-A63 BBT-40 |
|
| Spindle Cooling unit | Cooling capacity:4,000Kcal/hr (at25℃) Water cooling /Oil cooling |
||
| Spindle Weight | 80kg | 80kg | |
| Integral Encoder For Closed-Loop Control |
Option | ||
| Coolant Through Shaft (CTS) | Option | ||
| Tool Position Sensors | N/A | Analog sensor | |
| Front Bearing Temperature Sensor |
Standard | ||
Also available with grease lubrication.
This lubrication leads to speed reduction.
Compare Others Specifications
| Type | TH-170.03 (380V) |
THN-170.02(230V) THN-170.03(400V) |
TH-190.04 (400V) |
TH-210.01 (400V) |
||
|---|---|---|---|---|---|---|
| Spindle Ø | 170mm | 170mm | 170mm | 190mm | 210mm | |
| Maximum Speed (Oil-Air) Also available with grease lubrication. This lubrication leads to speed reduction. |
20,000rpm | 30,000rpm | 20,000rpm | 15,000rpm | 18,000rpm | |
| Bore diameter of front bearings | 65mm | 65mm | 70mm | 70mm | 70mm | |
| Rigidity | Axial (N/µm) |
150N/µm | 150N/µm | 180N/µm | 180N/µm | 180N/µm |
| Radial (N/µm) |
200N/µm | 200N/µm | 200N/µm | 200N/µm | 200N/µm | |
| Frequency Max. (Hz) | 667Hz | 1,000Hz | 667Hz | 800Hz | 1,200Hz | |
| at speed | 9,860rpm | 9,860rpm | 5,870rpm | 3,200rpm | 2,000rpm | |
| S1 kW | 30kW | 30kW | 18kW | 16kW | 15kW | |
| S6-40% kW | 39kW | 39kW | 23.4kW | 20.8kW | 19.5kW | |
| kW (Peak Power) | 106kW | 106kW | 58kW | 63kW | 83kW | |
| S1 Torque (Nm) | 29.1Nm | 29.1Nm | 29.3Nm | 47.8Nm | 71.6Nm | |
| S6-40% Torque (Nm) | 37.8Nm | 37.8Nm | 38.1Nm | 62.1Nm | 93.1Nm | |
| Tool Interface | BT-40 BBT-40 |
HSK-A63 HSK-E63 |
BT-40 BBT-40 |
HSK-A63 HSK-C63 |
HSK-A63 BBT-40 |
|
| Spindle Cooling | Water cooling /Oil cooling | |||||
| Spindle Weight | 63kg | 63kg | 65kg | 80kg | 100kg | |
| Integral Encoder For Closed-Loop Control |
Option | Option | Option | Option | Option | |
| Coolant Through Shaft (CTS) | Option | Option | Option | Option | Option | |
| Tool Position Sensors | Proximity switches / Analog sensor | |||||
| Front Bearing Temperature Sensor |
Standard | Standard | Standard | Standard | Standard | |
